Empty Aluminum Can Filling Line - Beverage Aluminum Can Rinser SUS304 With CE

Place of Origin : ZhangJiaGang City, JiangSu Province, China

Brand Name : FillPack

Certification : CE, ISO

Model Number : YFGC-1

Application : Food and beverage production line

Applicable can : New empty aluminum can or PET can

Water pump power : 0.37 KW

Material : SUS304

Driven Type : Electric

Condition State : New

Service : Engineer available to oversea service

Guarantee Time : 1 Year

MOQ : 1 set/pcs

Price : Negotiation

Packaging Details : Blanket cloth or wooden case pacakge

Delivery Time : 7-10 days

Payment Terms : 30% T/T deposit, 70% before shipment

Supply Ability : 60 sets/month

Contact Now

Empty Aluminum Can Filling Line - Beverage Aluminum Can Rinser SUS304 With CE

Quick Detail:

1. Capacity: 1000-2000 Cans / Hour

2. Avaliable to new empty aluminum can or PET can

3. Water pump for pure water or sterilized water ringsing

4. Main material: SUS304

5. Can rinser + can filler + can selaer

6. Manual put the cans into rinser

Description:

This can rinser is revolution inclined type can rinser;

One end of the cabinet is entrance of the cans, usually it need to work together with unpiler, if the client do not have unpiler, he will need to set up one high flat roof for manual loading of cans;

After the cans loading, they will be reversed 90 degree and pass the cabinet quickly with gravity when can mouth face to ground. The cabinet is inside set with 12 pcs of shower to spray water inside the cans to wash. After washing, the cans will be reversed again 90 degree to loaded on conveyor connected to filler.

The cabinet is connected with pump for water discharge. And the cabinet is with checking winder to check if any problem happen inside. And the roof of the cabinet is removable for repair and cleaning.

Operation process

1. Please put the can one by one to the can feeding conveyor by manual or the unpiler and open the water pump to wash.

2. The cans will be washed clean and will go forward with the manual push force.

3. The cans are through different direction and final stand up to the feeding conveyor of can filling machine.

Specifications:

Model YFGC-1
Capacity 1000-2000 Cans/H(500ml)
Material SUS304
Power 0.37 KW
Water pressure 0.15Mpa
Dimension L1500*W500*H1860mm
Weight 150kg
