Monoblock Drinking Water Filling Machine , Washing Filling and Sealing 3 in 1

Zhangjiagang City FILL-PACK Machinery Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Zhangjiagang City FILL-PACK Machinery Co., Ltd
Province/State: Jiangsu
Country/Region: China
Tel: 86-512-58643048
Contact Person:
Ms Alice Gu

Monoblock Drinking Water Filling Machine , Washing Filling and Sealing 3 in 1

Brand Name : FillPack
Model Number : CGF32-32-10
Certification : CE / ISO9001 - 2008
Place of Origin : Zhangjiagang, China
MOQ : 1 set
Price : 30000-35000 USD
Payment Terms : L/C, T/T, Western Union
Supply Ability : 20 Sets Per Months
Delivery Time : 30 Working Days After Deposit
Packaging Details : Wooden Case Package
Application : Non gas water
Automatic grade : Automatic
Fuction : washing filling capping in one unit
Capacity : 15000 bottles per hour
material : stainless steel
Automatic : Automatic
Warranty : 1 year
Function : Rinsing, filling, capping in one unit
Voltage : Customize
Product name : Drinking water filling machine
Processing line : Drinking water filling
Contact Now

Washing, Filling and Sealing 3 in 1 Monoblock Drinking Water Filling Machine


Quick Detail:


Machine: Small Bottle Automatic Water Filling Machine Monoblock

Applicative Bottle: PET bottle

Applicative cap: palstic screw cap

Applicative volume: 0.2 - 2L

Applicative liquid: non gas water
Production Capacity: 15000bph
Machine construction: washing filling capping 3 in 1

Advantage: USA - Germany technology

Service: Engineers availble to service Machinery overseas


Description:


1. This water filling machine : used for pure water,mineral water , drinking water filling into PET bottles,

or glass bottles.

2. The water filling machine is Wash-filling-capping 3-in-1unit.

3. The water filling machine is sutiable for 500-2000ml PET bottle filling, this machine can realize one

machine different size , just change the different star wheels.

4. The water filling machine capacity can be 1000-20000bph .

5. We strictly manufacture and manage according to IOS9001:2000 System.And we sincerely

welcome customers all over the world vist our company,or browse,visit our website.Any requirement,

please contact us via E-mail,we will provide beat service for customers.


Running principle:


1. Bottles are delivered by air conveyor to 3 in 1 unit of washing part. The bottle neck will be hold

tightly by clamp to upside down the bottles, which will not damage bottle. Then the bottles are

washed by pumped water.

2. After washing, bottles are rotated by the star-wheels to the filling position. Bottle neck is also

hold tightly by clamp. There is a cam to up and down the bottles to make bottle mouth position

with filling head, and then to realize filling. The filling volume and filling time will be pre-set in PLC.

3.After finish filling, bottles are still rotated by star-wheels to capping position. Here we design a bottle

caps unscrambler and an automatic cap dropping to make the caps drop correctly to bottle mouth. If

the cap is upside down or damaged, the machine will automatically delete the caps. After finish all

actions, bottles are delivered to the packaging line.


Advantages:


- Small in size

- High level of automation: PLC control, no bottle, no filling

- Easy operation and maintanance

- High level of filling precision

- Material: SUS 304


Main technical data:


ModelCGF8-8-3CGF12-12-4CGF18-18-6CGF24-24-8CGF32-32-10
Washing Head No812182432
Filling Head No812182432
Capping Head No346810

Rated

Capacity

(500ml)

3000BPH4000BPH7000-8000BPH10000-15000BPH15000-20000BPH
Overall Size

1900*1420*

2000mm

2200*1600*

2300mm

2450*1900*

2300mm

2750*1180*

2400mm

4000*2300*

2300mm

Weight1.5T2.2T3.0T4.0T8.0T

Power

(KW)

3.0kw3.5kw4.0kw4.8kw7.6kw
Rated VoltageCustomizedCustomizedCustomizedCustomized

Customized


After-sales service:


1. One year warranty for the whole system

2. Free equipment installation and debugging

3. After one year, we can help you to maintain the machine and the accessories are provided only

one the cost price

4. Every 3 years, we can help to overhaul the machine free (Labor)

5. We can provide internship service and help you train the operator and mechanic

6. Free production technology and process configuration

7. We can help you to design the production line, workshop and provide turn-key project
